APP Monitor
Powerful and Reliable 5~10 Years Service Life
Environmental Friendly
Built-in Safety ProtectionIntelligent Bluetooth
BMS Support Parellels
|
Normal
|
|||||
|
Model
|
48V 100AH
|
48V 200AH
|
51.2V 100AH
|
51.2V 200AH
|
51.2V 300AH
|
|
Battery Type
|
LiFePO4(LFP)
|
LiFePO4(LFP)
|
LiFePO4(LFP)
|
LiFePO4(LFP)
|
LiFePO4(LFP)
|
|
Norminal Voltage(V)
|
48V
|
48V
|
51.2V
|
51.2V
|
51.2V
|
|
Norminal Capacity(WH)
|
4800WH
|
9600WH
|
5120WH
|
10240WH
|
15360WH
|
|
Usable Capacity(WH)
|
3840WH/80%DOD
|
7680WH/80%DOD
|
4096WH/80%DOD
|
8192WH/80%DOD
|
12288WH/80%DOD
|
|
Design Life
|
10+Years(25℃/77T)
|
10+Years(25℃/77T)
|
10+Years(25℃/77T)
|
10+Years(25℃/77T)
|
10+Years(25℃/77T)
|
|
Physical
|
|||||
|
Dimension(mm)
|
470*490*220mm
|
560*600*275.5mm
|
470*490*220mm
|
560*600*275.5mm
|
580*278*900mm
|
|
Weight(kg)
|
50kg
|
90kg
|
51kg
|
95kg
|
150KG
|
|
Electrical
|
|||||
|
Cycle Life
|
>6000,25℃
|
>6000,25℃
|
>6000,25℃
|
>6000,25℃
|
>6000,25℃
|
|
Discharge Voltage(V)
|
40~58.4
|
40~58.4
|
40~58.4
|
40~58.4
|
40~58.4
|
|
Charge Voltage(V)
|
56~58.4
|
56~58.4
|
56~58.4
|
56~58.4
|
56~58.4
|
|
Charge/Discharge Current(A)
|
50A(Recommended)
|
50A(Recommended)
|
50A(Recommended)
|
50A(Recommended)
|
100A(Recommended)
|
|
100A (Max)
|
100A (Max)
|
100A (Max)
|
100A (Max)
|
200A (Max)
|
|
|
Internal Resistance
|
≤30mΩ
|
≤30mΩ
|
≤30mΩ
|
≤30mΩ
|
≤30mΩ
|
|
BMS
|
|||||
|
Capacity
|
100A (Max)
|
100A (Max)
|
100A (Max)
|
100A (Max)
|
200A (Max)
|
|
Power Consumption
|
<2W(Work)<100mW(Sleep)
|
<2W(Work)<100mW(Sleep)
|
<2W(Work)<100mW(Sleep)
|
<2W(Work)<100mW(Sleep)
|
<2W(Work)<100mW(Sleep)
|
|
Monitoring Parameters
|
System voltage, current, cell voltage,cell temperature,module temperature
|
System voltage, current, cell voltage,cell temperature,module temperature
|
System voltage, current, cell voltage,cell temperature,module temperature
|
System voltage, current, cell voltage,cell temperature,module temperature
|
System voltage, current, cell voltage,cell temperature,module temperature
|
|
SOC
|
ntelligent algorithm
|
ntelligent algorithm
|
ntelligent algorithm
|
ntelligent algorithm
|
ntelligent algorithm
|
|
Communication
|
CAN/RS-485/RS-232
|
CAN/RS-485/RS-232
|
CAN/RS-485/RS-232
|
CAN/RS-485/RS-232
|
CAN/RS-485/RS-232
|
|
Operation
|
|||||
|
Operating Temperature Range
|
10℃~50℃
|
10℃~50℃
|
10℃~50℃
|
10℃~50℃
|
10℃~50℃
|
|
Transport or Storage Temperature Range
|
-20℃~45℃
|
-20℃~45℃
|
-20℃~45℃
|
-20℃~45℃
|
-20℃~45℃
|
|
Humidity
|
15%~85%(No Condensing)
|
15%~85%(No Condensing)
|
15%~85%(No Condensing)
|
15%~85%(No Condensing)
|
15%~85%(No Condensing)
|
|
Warranty
|
|||||
|
Product Warranty
|
5 Years
|
5 Years
|
5 Years
|
5 Years
|
5 Years
|
|
Pergormance Warranty
|
10 Years
|
10 Years
|
10 Years
|
10 Years
|
10 Years
|
Contact us for more discount information!
